Elon Musk made plenty of guarantees throughout Tesla’s Battery Day last September. Soon, he stated, the corporate would have a automobile that runs on batteries with pure silicon anodes to increase their efficiency and reduced cobalt in the cathodes to decrease their worth. Its battery pack will probably be built-in into the chassis in order that it gives mechanical help in addition to energy, a design that Musk claimed will scale back the automobile’s weight by 10 p.c and enhance its mileage by even more. He hailed Tesla’s structural battery as a “revolution” in engineering—however for some battery researchers, Musk’s future seemed rather a lot just like the previous.
“He’s essentially doing something that we did 10 years ago,” says Emile Greenhalgh, a supplies scientist at Imperial College London and the engineering chair in rising applied sciences at the Royal Academy. He’s one of many world’s main specialists on structural batteries, an method to energy storage that erases the boundary between the battery and the thing it powers. “What we’re doing is going beyond what Elon Musk has been talking about,” Greenhalgh says. “There are no embedded batteries. The material itself is the energy storage device.”
Today, batteries account for a considerable portion of the scale and weight of most electronics. A smartphone is principally a lithium-ion cell with some processors stuffed round it. Drones are restricted in measurement by the batteries they’ll carry. And a couple of third of the burden of an electrical car is its battery pack. One approach to deal with this concern is by constructing typical batteries into the construction of the automobile itself, as Tesla plans to do. Rather than utilizing the ground of the automobile to help the battery pack, the battery pack turns into the ground.
But for Greenhalgh and his collaborators, the more promising method is to scrap the battery pack and use the car’s physique for energy storage as an alternative. Unlike a traditional battery pack embedded in the chassis, these structural batteries are invisible. The electrical storage occurs in the skinny layers of composite supplies that make up the automobile’s body. In a way, they’re weightless as a result of the automobile is the battery.
“It’s making the material do two things simultaneously,” says Greenhalgh. This new mind-set about EV design can present large efficiency positive aspects and enhance security as a result of there gained’t be hundreds of energy-dense, flammable cells packed into the automobile.
Table of Contents
A better look
A lithium-ion battery inside a cellphone or EV battery pack has 4 essential parts: the cathode, anode, electrolyte, and the separator. When a battery is discharged, lithium-ions movement by means of the electrolyte from the damaging anode to the constructive cathode, which are partitioned by a permeable separator to forestall a short circuit. In a traditional battery, these components are both stacked like a marriage cake or wound round one another like a jelly roll to pack as a lot energy as attainable right into a small quantity. But in a structural battery, they’ve to be reconfigured so the cell may be molded into irregular shapes and stand up to bodily stress. A structural battery doesn’t appear to be a dice or a cylinder; it seems to be like an airplane wing, automobile physique, or cellphone case.
The first structural batteries developed by the US navy in the mid-2000s used carbon fiber for the cell’s electrodes. Carbon fiber is a light-weight, ultrastrong materials that is incessantly used to form the bodies of aircraft and high-performance cars. It’s additionally nice at storing lithium ions, which makes it a great substitute for different carbon-based mostly supplies like graphite which might be used as anodes in typical Li-ion batteries. But in a structural battery, carbon fiber infused with reactive supplies like iron phosphate is additionally used for the cathode as a result of it wants to present help. A skinny sheet of woven glass separates the 2 electrodes, and these layers are suspended in an electrolyte like fruit in an electrochemical jello. The complete ensemble is only some millionths of a meter thick and may be reduce into any desired form.
A “structural parasite”
Leif Asp, a supplies scientist at the Chalmers University of Technology in Sweden, has been at the forefront of structural battery analysis for the previous decade. In 2010, Asp, Greenhalgh, and a group of European scientists collaborated on Storage, a challenge that aimed to construct structural batteries and combine them right into a prototype hybrid Volvo.
“At that time, I didn’t think it would have much impact on society, but as we moved along it struck me that this could be a very useful idea,” says Asp, who characterizes the traditional battery as a “structural parasite.” He says the primary good thing about structural batteries is that they scale back the quantity of energy an EV wants to drive the identical distance—or it could improve its vary. “We need to focus on energy efficiency,” says Asp. In a world the place most electrical energy is nonetheless produced with fossil fuels, each electron counts in the combat in opposition to local weather change.
During the three-yr challenge, the Storage group efficiently built-in business lithium-ion batteries right into a plenum cowl, a passive part that regulates air consumption into the engine. It wasn’t the automobile’s essential battery, however a smaller secondary pack that equipped electrical energy to the air-conditioning, stereo, and lights when the engine quickly turned off at a cease mild. This was the primary proof of idea for a structural battery that was built-in into the physique of a working automobile and was primarily a small-scale model of what Tesla is attempting to obtain.
But sandwiching a bunch of typical Li-ion cells into the physique of a automobile isn’t as environment friendly as making the automobile’s physique serve as its personal battery. During the Storage collaboration, Asp and Greenhalgh additionally developed a structural supercapacitor that was used as a trunk lid. A supercapacitor is comparable to a battery however shops energy as electrostatic cost, relatively than a chemical response. The one made for the Volvo trunk consisted of two layers of carbon fiber infused with iron oxide and magnesium oxide, separated by an insulating layer. The complete stack was wrapped in laminate and molded into the form of the trunk.
